Ventilation system_set 02
The set has 20 multi-colored ceilings with ventilation ducts.
The model has a fragment of the ceiling as a preview and all the elements in disassembled form. There are more than 500 unique elements in the collection.
– 3 types of ventilation channels of square section with all components, fastenings, diffusers.
Sections 20 * 20cm, 30 * 30cm, 30 * 50cm.
– 1 type of ventilating pipes of round section with all components, fastenings, diffusers, pressure equalization chambers.
Diameter 20cm, 30cm, 40cm.
– 1 type of ventilating pipes of oval section with all components, fastenings.
– 4 cassette conditioners (in 20 colors).
– Trays for electric cables.
– Electrical cables with all components, holders, junction boxes (in 20 colors).
– Electrical cables in PVC pipes with all components, holders (in 20 colors).
– Fire protection system, smoke sensor (in 20 colors).
– 24 types of metal materials for pipes: glossy aluminum, glossy aluminum with abrasions, brushed aluminum, brushed aluminum with abrasions, white, black, gray and 17 more colors (seamless texture, resolutions 8000×8000 pixels)
– 20 materials of a concrete ceiling (seamless textures with high resolution, resolutions of 8000×8000 pixels)
High quality 3d model.
The archive contains:
.max_2014_VRay 3.60.03
.max_2014_Corona 4
.obj
.jpg
The model is fully textured with all materials used. All textures and materials are included and displayed in each format. Objects and materials are logically named for the convenience of stage management.
Preliminary rendering using Corona.
Units of measurement: mm
Polys: 1,459,428 Verts: 1,486,505
Who works in V-Ray version lower than 3.1, be careful, in the materials in the BRDF section there is Microfaset GTR (GGX), if your version is older than 3.1, the BRDF field will be empty. Choose Blinn, Phong or Ward – whichever is preferable for you
